Product Outline

ChargePoint is a unit of split butterfly valves for transferring highly activated materials. This system is available for any occasions in the pharmaceutical processes. ChargePoint is comprised of active part and passive part. By docking both parts, the valve becomes one unit of butterfly valve. Then, open/close process and transferring of powders in a contained condition becomes possible. After transferring the powder, valves are closed and separated. At this time, the inner side of each valve is kept clean because it does not touch the powder material.

Features

• OEL less than 10μg/m3 is possible with a standard type. With the combination of options such as the vortex system, OEL less than 1μg/m3 can be achieved.
• FV～0.6MPa(Gauge) is available with pressure resistance types.
• We offer various options such as CIP system, feeding system, docking station, sight glass, etc.

Application Examples

• Feeding and discharging of materials to IBC containers.
• Feeding materials to reactors.
• Feeding and discharging materials to glove box.

Practical Use

• Handling of pharmaceutical materials
• Handling of materials which requires protection from oxidization.
• Handling of activated materials.
